Fig-010
Flat gate valve
non rising stem
body: cast iron GG25
seat: brass
flanged PN10
DN40 - DN300
Fig-013
Flat gate valve
rising stem
body: cast iron GG25
seat: min. 11,5Cr
flanged PN10
DN40 - DN300
Fig-018
Flat gate valverising stem
body: carbon steel GS-C25
seat: 13Cr
flanged PN10 / 16
DN40 - DN400
Fig-021
Gate valve
non rising stem
body: cast iron FT25
seat: 13Cr
flanged PN16
DN40 - DN300
Fig-030
Gate valve
rising stem
body: carbon steel GS-C25
seat: 13Cr
flanged PN10
DN200 - DN600
Fig-031
Gate valverising stem
body: carbon steel GS-C25
seat: 13Cr
flanged PN16
DN65 - DN600
Fig-032
Gate valverising stem
body: carbon steel GS-C25
seat: 13Cr
flanged PN25
DN65 - DN600
Fig-033
Gate valverising stem
body: carbon steel GS-C25
seat: 13Cr
flanged PN40
DN40 - DN600
Fig-034
Gate valverising stem
body: forged steel A105
contacts: 13Cr
flanged PN40
DN15 - DN40
Fig-040
ANSI Gate valve
rising stem
rising stem
body: carbon steel A216 WCB
trim: N° 8
flanged series 150 lbs
DN 2 "- 20"
Fig-041
ANSI Gate valve
rising stem
rising stem
body: carbon steel A216 WCB
trim: N° 8
flanged series 300 lbs
DN 2 "- 20"
Fig-042
ANSI Gate valve
rising stem
rising stem
body: carbon steel A216 WCB
trim: N° 8
flanged series 600 lbs
DN 2 "- 20"
